Bodine FirstLink LED Exit Sign Emergency Light Combo, Green Letters, White Housing, BXAGWFL1
- ROCK SKU: BOD-BXAGWFL1
- MFG Part #: BXAGWFL1
$116.92
Product dimensions
-
Width:
8.7 IN
-
Height:
13.75 IN
-
Depth:
2.13 IN
-
Weight:
2.9 LBS
The Bodine BXA FirstLink Connected Exit Sign is a battery-backup LED exit sign designed for code-compliant emergency egress lighting with built-in wireless connectivity and FirstLink compatibility.
- It includes a maintenance-free lithium-ion battery that provides a minimum of 90 minutes of emergency illumination and automatically recharges within 24 hours
- and it supports universal mounting (wall
- ceiling
- or end mount) with single- or double-face configuration options.
- The exit sign is UL 924 listed for field installation in the US and Canada and is suitable for indoor and damp-location applications
- making it ideal for commercial buildings such as offices
- schools
- retail spaces
- and industrial facilities.
| UL LISTED FOR US & CANADA | Listed to UL 924 for Field Installation in the US and Canada (Indoor and Damp); DOE Compliant |
| Illumination Time | 90 Minutes |
| Full Warranty | 5 Years (NOT pro-rata) |
| Universal Input Voltage | 120-277 VAC |
| 50/60 Hz | Universal Input Voltage |
| 120-277 VAC | 50/60 Hz |
| Construction | White thermoplastic housing; UL94 5VA Flame Rated; UV stable; Contractor friendly snap together design; Electronics and battery contained within housing |
| Installation | Universal wall/end/ceiling mounting (universal mounting adapter provided for wall and end mounting); Back plate keyhole slots are easily removable knockouts for securing to a 3 or 4 j-box; Pop-out directional indicating chevrons easily removed as required |
| Extra stencil face plate provided for double faced applications | Battery |
| High-Temperature | Maintenance-Free Lithium-Ion Battery; 7- to 10-Year Life Expectancy |
| Recharge Time | 24 Hours |
| Temperature Rating (Ambient) | 50° F to 104° F (10° C to 40° C) |
Product dimensions
-
Width:
8.7 IN
-
Height:
13.75 IN
-
Depth:
2.13 IN
-
Weight:
2.9 LBS
