/ radiant® Multi-Location Master Dimmer, White
radiant® Multi-Location Master Dimmer, White
- ROCK SKU: HCL453PMMW
- UPC: 785007039665
- MFG Part #: HCL453PMMW
$57.20
$40.86
Product dimensions
-
Width:
1.25 in
-
Height:
4.25 in
-
Depth:
2.5 in
-
Weight:
Allows precise dimming control of a light or fixture. Pair with a Multi-Location Remote Dimmer to control the same fixture from another spot in the room. Part of the radiant® Collection, it also features clean lines and smooth control for a sophisticated touch. Made exclusively for use with screwless Wall Plates from the radiant® Collection, sold separately.
- For use with most incandescent, CFL/LED (with the exception of 0 - 10v options) and MLV dimmable bulbs. Installs easily with 3-way wiring for multi-location dimming (use with up to nine remote dimmers).
- Can also be used in single-pole applications for solitary control.
- Low-profile paddle switch offers smoother On/Off control, while a separate, ergonomic slider allows you to adjust light levels with precision.
- Locator light illuminates when switch is off, emitting a soft glow to help you find it in the dark.
- Constant memory features returns lights to their previous level after a power failure or outage.
- No derating* required in multi-gang applications. *Reducing the maximum wattage a dimmer can handle. This is sometimes required for multi-gang applications.
- Features durable, high-impact resistant thermoplastic construction.
- More color options available to fit any style, including finishes to match current hardware and lighting trends.
- Complete the look with a sleek, screwless radiant® Wall Plate, and coordinate with other designer switches and outlets available from the radiant® Collection.
| Brand | Wattstopper |
| Color | White |
| Type | Dimmer |
| Finish | Matte |
| Application Sector | Residential |
| Product Line | Pass & Seymour |
| Country Of Origin | China |
| Features | Color Change Kit, High-End Trim (Dim Range), Locator Light, Low-End Trim (Dim Range) |
| Number of Switches | 1 |
| Switch Type | Digital, Paddle |
| Warranty Type | Limited Lifetime Warranty |
| Standard | CSA Listed, cULus, UL Listed |
| Requires Neutral Wire | No |
| Wire Connection Type | Screw Terminals |
| Dimming Compatibility | Forward Phase |
| Environmental Conditions | Humidity: Less than 95% non condensing |
| Frequency Rating | 60 Hz |
| Indoor/Outdoor | Indoor |
| Load Rating | 120V 450W (CFL), 120V 450W (LED), 120V 700VA (MLV), 120V 700W (Halogen), 120V 700W (Incandescent) |
| Load Type | CFL, Incandescent, LED |
| Mounting Type | Wall Box |
| Number of Poles | Multi-Location, Single Pole 3-Way |
| Voltage | 120 VAC |
| Wire Size | #14 - #10 AWG |
