RAB LED Floodlight Buying Guide: How to Pick the Right Flood

RAB makes a flood for almost every outdoor job: façades, parking lots, loading docks, athletic fields, signage, flags, and monuments. The trick is matching the family and lumen package to the application and budget. This guide walks the RAB floodlight lineup and the specs that actually decide the pick, all from RAB's published data.

Buy by lumens and MH replacement, not watts

LED wattage no longer maps cleanly to brightness, so spec by lumens and by the metal halide (MH) wattage the fixture replaces. RAB publishes both for every flood. As a quick orientation across the families:

• A 150W FXLED replaces a 400W MH (10,000–21,000 lm across the 78W–150W FXLED group).
• A 500W FXLED replaces up to two 1000W MH fixtures (31,000–63,000 lm for the 200W–500W group).
• A 230W FFLED replaces up to a 1000W MH (16,700–34,000 lm).
• An 80W FFLED replaces a 400W MH (4,000–10,400 lm).

The RAB floodlight families at a glance

FXLED, premium and most versatile (the high-output choice)

• Two groups: 78W–150W (10,000–21,000 lm, up to 128 lm/W) and 200W–500W (31,000–63,000 lm, up to 132 lm/W).
• Up to 5 beam distributions on the large group, built for wide-open areas, large façades, and athletic fields.
• The 500W delivers security-level illumination about 150 ft from the fixture.
• Slipfitter or trunnion mount, 480V option, DLC Standard and Premium, IP66, 100,000-hour rated life.

FFLED, mid-range value and field-adjustable (the everyday workhorse)

• Spans 9W–230W across 3 sizes and 8 wattages, up to 34,000 lm and up to 151–152 lm/W, among the most efficient floods RAB makes.
• Field-adjustable wattage and selectable CCT (4000K / 5000K), with static 3000K models available for Dark Sky and municipality requirements.
• Up to 3 distributions; slipfitter, trunnion, or (smaller models) swivel-arm mount; 480V option; DLC Standard and Premium; IP66; 100,000-hour rated life.
• Control-ready: button photocell, 7-pin receptacle, or RAB Lightcloud-enabled twistlock photocell.

EZLED, narrow-beam spotlight

• 78W, up to 10,000 lm, replaces up to a 400W MH, and throws a concentrated beam to illuminate objects up to 80 ft away.
• Ideal for flags, monuments, steeples, and bridges. 2 distributions, slipfitter or trunnion mount.

PIP / PIPXL, economy and contractor-grade

• PIP 15W–45W: 2,000–6,400 lm (45W replaces up to 250W MH). PIPXL 70W and 100W: 10,600–16,600 lm (100W replaces up to 750W PSMH).
• 0–10V dimming standard, IP66, DLC Standard and Premium, 60,000-hour rated life, 5-year limited warranty.

LESLIE, economy bullet flood

• 13W, up to 1,200 lm, roughly a 75W BR equivalent, low-profile with even distribution. Good for landscape and building/grounds lighting, Energy Star rated.

Specs that decide the pick

Beam distribution. RAB labels distributions from 7H×6V (wide) down to 3H×3V (narrow/spot). Wide distributions cover open areas and lots; narrow ones throw light farther for façades, fields, and feature lighting.

Mounting. Match it to the structure: slipfitter (onto a tenon or pole), trunnion (yoke or surface), or swivel-arm on smaller FFLEDs.

Voltage. Standard 120–277V covers most jobs. FXLED and FFLED offer 480V models for commercial and industrial gear.

Color temperature. FFLED's selectable 4000K/5000K covers most commercial needs. Choose the static 3000K where Dark Sky or local ordinances apply.

Controls. For dusk-to-dawn, add a photocell. For energy code or scheduling, choose dimmable drivers (0–10V on PIP/PIPXL) or RAB's Lightcloud-enabled photocell on FFLED. California outdoor jobs have control requirements; see Title 24.

Wet location and life. The premium and mid families are IP66 rated and 100,000-hour rated. Economy PIP/LESLIE are rated to 60,000 hours.

DLC for rebates. FXLED, FFLED, and PIP/PIPXL include DLC-listed models, which matters for utility rebate eligibility.

Warranty. RAB's current FXLED and FFLED field-adjustable floods carry a 10-year, no-compromise warranty per RAB's product pages. (RAB's older flood-family overview page still lists 5-year on some models, so confirm the term on the specific model's spec sheet.) Economy PIP/PIPXL carry a 5-year limited warranty.

Which family should you pick?

• High output, fields, or big façades: FXLED, especially 200W–500W.
• Most parking lots, yards, signage, and general commercial: FFLED, where field-adjustable wattage and CCT make it easy to standardize.
• Feature and spot lighting (flags, monuments): EZLED.
• Tight budget, general flooding: PIP / PIPXL.
• Small landscape and building accents: LESLIE.

Need colored light? FXLED, FFLED, and EZLED offer 11 colored-lens options.

Buy RAB floods from Rock

Rock Lighting & Electric is an authorized RAB dealer and distributor: genuine product, correct model selection, and full warranty backing, at contractor pricing. Browse RAB at Rock, including the FXLED trunnion flood, or pair this with our RAB LED wall pack buying guide. Doing a full site? Send us your plans and we'll spec the floods and quote it. Contact us.

FAQ

Specifications can change and RAB lists more than one generation of some families. Confirm lumens, wattage, ratings, and warranty for the exact catalog number on RAB's current spec sheet before ordering.
