Westgate Mfg X-Gen Flat Glass Wall Pack, 20/30/40W, CCT Selectable, 0-10V, Photocell, Vandal-Resistant, Bronze, WPFX-MD-20-40W-MCTP-P
- ROCK SKU: WES-WPFX-MD-20-40W-MCTP-P
- UPC: 845060092509
- MFG Part #: WPFX-MD-20-40W-MCTP-P
$149.78
$132.74
The Westgate Mfg WPFX-MD-20-40W-MCTP-P is an X-Gen flat glass LED wall pack rated at 20/30/40W delivering 135 lm/W, suited for entryways, walkways, and building perimeters where low-to-mid output and a low-profile aesthetic are required. Three selectable CCT settings (3000K/4000K/5000K), 0-10V dimming, an integrated photocell, and vandal-resistant screw hardware provide control flexibility and durability in public-facing installations. Rated IP65 with a BUG rating of B2-U2-G2, UL listed and DLC Premium qualified, backed by a 7-year warranty; operates on 120–277V.
| Watts | 20/30/40W (Field-Adjustable) |
| Lumens | 2,700–5,400 lm |
| Color Temperature | CCT Selectable (3000K/4000K/5000K) |
| Voltage | 120-277V |
| Dimming | 0-10V |
| IP Rating | IP65 |
| Beam Angle | 127° H × 85° V |
| BUG Rating | B2-U2-G2 |
| Listings | UL, DLC Premium |
| Warranty | 7 Years |
| Finish | Bronze |
