Westgate Mfg Full-Lens Wall Sconce, 18/20/22W, CCT Selectable, 120-277V, TRIAC/0-10V Dimming, Oil-Rubbed Bronze, LDSX-L-18-22W-MCTP-ORB
- ROCK SKU: WES-LDSX-L-18-22W-MCTP-ORB
- UPC: 845060012668
- MFG Part #: LDSX-L-18-22W-MCTP-ORB
$76.78
$67.74
The Westgate Mfg LDSX-L-18-22W-MCTP-ORB is a 14" full-lens LED wall sconce designed for commercial and residential entryway, corridor, and building facade applications on 120–277V. Selectable at 18W, 20W, or 22W at 100 LM/W with field-adjustable CCT (3000K/4000K/5000K) and dual-mode TRIAC and 0-10V dimming, it integrates with a wide range of commercial dimming systems. ETL and Energy Star listed with a 7-year warranty, IP42 rated, and finished in oil-rubbed bronze.
| Watts | 18/20/22W (Field-Adjustable) |
| Lumens | 1,800–2,200 lm |
| Color Temperature | CCT Selectable (3000K/4000K/5000K) |
| CRI | 80 |
| Voltage | 120–277V |
| Dimming | TRIAC & 0–10V |
| Rated Life | 50,000 hrs |
| IP Rating | IP42 |
| Finish | Oil-Rubbed Bronze |
| Listing | ETL, ES |
