RAB Lighting A22 Area Light, 100/80/60W, CCT Selectable, 480V, Type II Pole Mount, MVS, Bronze, A22-2T100/480/MVS
- ROCK SKU: RAB-A22-2T100/480/MVS
- UPC:
- MFG Part #: A22-2T100/480/MVS
The RAB Lighting A22-2T100/480/MVS is a field-adjustable 100/80/60W LED area light with Type II pole-mount optics, designed for roadways, parking lots, and pedestrian pathways on 480V systems with MVS photocell control. CCT-selectable across 3000/4000/5000K, it delivers up to 14,503 lumens at efficacy up to 158.1 lm/W and holds DLC Premium listing (ID: S-NZX3BD). Rated for 100,000 hours in a bronze finish.
| Watts | 100/80/60W (Field-Adjustable) |
| Lumens | 9,075–14,503 lm |
| Color Temperature | CCT Selectable (3000K/4000K/5000K) |
| Voltage | 480V |
| Efficacy | 131.4–158.1 lm/W |
| Rated Life | 100,000 hours |
| DLC | DLC Premium (S-NZX3BD) |
| Finish | Bronze |
