/ PIR Wall Switch Occupancy Sensor, 347V, White
PIR Wall Switch Occupancy Sensor, 347V, White
- ROCK SKU: WS-301-347-W
- UPC: 754182936069
- MFG Part #: WS-301-347-W
$87.70
$62.64
Product dimensions
-
Width:
1.8 in
-
Height:
4.5 in
-
Depth:
35.1 cu in
-
Weight:
1.8 in
The WS-301 Passive Infrared (PIR) Wall Switch Sensor turns lighting or fan loads on and off based on occupancy and ambient light level. The sensor replaces existing wall switches and fits behind a standard decorator wall plate.
- Zero crossing circuitry reduces stress on the relay and results in increased sensor life
- 180° coverage, maximum of 900 ft2
- Adjustable time delay and sensitivity
- Custom two-tier Fresnel lens enhances detection at the desktop level
- Light level sensor holds lights off when ambient lighting is above the preset level
- Patented voltage drop protection
- Defaults to Manual-ON operation for maximum energy savings
- Shallow (1-inch) back housing and flying leads for easy installation
- Optional neutral connection with break off tab to expose neutral terminals
- Built-in light level sensor
- 120/240/277 VAC and 347 VAC models
| Color | White |
| Product Series | WS-301 |
| Type | Sensor, Switch |
| Finish | Glossy |
| Application Sector | Commercial |
| Product Line | Wattstopper |
| Country Of Origin | China |
| Features | Adjustable Time Delay, Indicator Lights, Light Level Sensor, Sensitivity Adjustment |
| Included | Mounting Screws, Sensor Mask |
| Installation Location | Wall |
| Switch Type | Motion Sensor |
| Warranty Type | 5-Year |
| Standard | UL, cUL |
| Number of Rockers | 0 |
| On Function | Selectable Auto/Manual |
| Requires Neutral Wire | No |
| Wire Connection Type | Flying Leads |
| Has Battery | No |
| Indicator | PIR Detection LED |
| Indoor/Outdoor | Indoor |
| Input Voltage | 347 VAC |
| Line Frequency | 50 Hz, 60 Hz |
| Load Rating | 1500 W @ 347 VAC |
| Mounting Type | In-Wall |
| Number of Buttons | 1 |
| Number of Poles | Single Pole |
Product dimensions
-
Width:
1.8 in
-
Height:
4.5 in
-
Depth:
35.1 cu in
-
Weight:
1.8 in
