Westgate Mfg 1x4 Backlit Troffer, 25/30/35W, CCT Selectable, 0-10V Dimming, LTRB-1X4-MCTP
- ROCK SKU: WES-LTRB-1X4-MCTP
- UPC: 845060084962
- MFG Part #: LTRB-1X4-MCTP
$122.78
$108.74
The Westgate Mfg LTRB-1X4-MCTP is a 1x4 backlit LED troffer available in 25/30/35W, designed for commercial ceiling grid applications including offices, classrooms, and healthcare facilities. Featuring SMD 2835 chip technology with a polystyrene lens delivering 110 lm/W efficacy, field-selectable CCT (3500/4000/5000K), and 0-10V dimming on 120–277V, the fixture provides uniform, low-glare illumination. UL listed with a 50,000-hour rated life and 5-year warranty.
| Watts | 25/30/35W (Field-Adjustable) |
| Lumens | 2,750–3,850 lm |
| Color Temperature | CCT Selectable (3500K/4000K/5000K) |
| CRI | 80+ |
| Voltage | 120–277V |
| Dimming | 0–10V |
| Rated Life | 50,000 hrs |
| Finish | White |
| LED Type | SMD 2835 |
| Lens | Polystyrene |
