Elco Lighting Cedar System 4 In. LED New Construction Housing, IC Airtight, 850 lm, 120/277V, Triac/ELV/0-10V Dimming, E4LC08ICAD2
- ROCK SKU: ELC-E4LC08ICAD2
- UPC: 633999139781
- MFG Part #: E4LC08ICAD2
$53.91
The Elco Lighting E4LC08ICAD2 is a 4-inch Cedar™ System new construction LED recessed housing with an integral driver, built for residential and light-commercial ceilings. It runs on 120/277V line voltage and delivers 850 lumens, dimming with Triac/ELV phase controls or 0-10V dimming. The IC airtight housing is sealed to ASTM E-283 against air leakage, rated for damp locations, holds a power factor above 0.95, and meets Title 24 JA8. Color temperature, CRI, and wattage are determined by the separately ordered Cedar™ System 4" LED light engine, so output and appearance can be matched to each space. USA designed and assembled and backed by a 5-year limited warranty.
| Aperture | 4 In. |
| IC Rating | IC Airtight |
| Housing Type | New Construction |
| Lumens | 850 lm |
| Voltage | 120/277V |
| Dimming | Triac/ELV/0-10V |
| Location | Damp |
| Power Factor | ≥0.95 |
| Warranty | 5-Year Limited |
| Light Engine | Ordered separately — sets CCT, CRI & wattage |
