Elco Lighting Cedar System 6 In. LED New Construction Housing, Non-IC Airtight, 2000 lm, 120/277V, Triac/ELV/0-10V Dimming, 90-Min Emergency, E6LC20D2-EM2
- ROCK SKU: ELC-E6LC20D2-EM2
- MFG Part #: E6LC20D2-EM2
$252.00
The Elco Lighting E6LC20D2-EM2 is a 6-inch Cedar™ System new construction LED recessed housing with an integral driver, built for residential and light-commercial ceilings. It runs on 120/277V line voltage and delivers 2000 lumens, dimming with Triac/ELV phase or 0-10V controls. The non-ic airtight housing is sealed to ASTM E-283 against air leakage, rated for damp locations, holds a power factor above 0.95, and meets Title 24 JA8. Color temperature, CRI, and wattage are determined by the separately ordered Cedar™ System 6" LED light engine, so output and appearance can be matched to each space. USA designed and assembled and backed by a 5-year limited warranty. An integrated 90-minute emergency battery backup keeps the fixture illuminated during a power loss.
| Aperture | 6 In. |
| IC Rating | Non-IC Airtight |
| Housing Type | New Construction |
| Lumens | 2000 lm |
| Voltage | 120/277V |
| Dimming | Triac/ELV/0-10V |
| Location | Damp |
| Power Factor | ≥0.95 |
| Warranty | 5-Year Limited |
| Light Engine | Ordered separately — sets CCT, CRI & wattage |
| Emergency Backup | 90-Minute Battery |
