Westgate Mfg CDLX X-GEN Surface Canopy, 15/25/35/45W, 4000K, 0-10V Dimmable, IP65, Bronze, CDLX-MD-15-45W-40K
- ROCK SKU: WES-CDLX-MD-15-45W-40K
- UPC: 845060072471
- MFG Part #: CDLX-MD-15-45W-40K
$120.78
$106.74
The Westgate Mfg CDLX-MD-15-45W-40K is a 15/25/35/45W adjustable LED surface canopy in the X-GEN CDLX medium-housing series, suited for fuel station canopies, covered parking entries, and commercial soffit applications. Delivering 120 lm/W at 4000K with a 140×140° beam and 0–10V dimming on 120–277V, it provides broad output control for energy code compliance. UL listed and DLC Premium qualified with an IP65 rating, 50,000-hour lifespan, and a 7-year warranty; bronze aluminum housing rated for –40°F to +104°F.
| Watts | 15/25/35/45W (Field-Adjustable) |
| Lumens | 1,800–5,400 lm |
| Color Temperature | 4000K |
| Dimming | 0-10V |
| IP Rating | IP65 |
| Rated Life | 50,000 hours |
| Certifications | UL, DLC Premium |
| Finish | Bronze |
| Warranty | 7 years |
