/ RAB Lighting A17 III Field-Adjustable LED Area Light,...
RAB Lighting A17 III Field-Adjustable LED Area Light, 480/400/320W, CCT Selectable, 480V, 7-Pin Photocontrol Receptacle, Pole Mount, Bronze, A17-3T480/480/7PRS
- ROCK SKU: RAB-A17-3T480/480/7PRS
- UPC:
- MFG Part #: A17-3T480/480/7PRS
The RAB Lighting A17-3T480/480/7PRS is a 3-arm field-adjustable LED area light rated at 480/400/320W at 480V with an integrated 7-pin photocontrol receptacle for advanced wireless or networked photocell control. Delivering CCT-selectable 3000K/4000K/5000K output and up to 76,317 lumens, this DLC Premium-listed fixture suits parking lots, roadways, and smart-ready outdoor installations requiring 7-pin NEMA receptacle compatibility.
| Watts | 480/400/320W (Field-Selectable) |
| Color Temperature | CCT Selectable (3000K/4000K/5000K) |
| Lumens | 49,556–76,317 lm |
| Efficacy | 146–171.1 lm/W |
| Voltage | 480V |
| Photocontrol | 7-Pin Receptacle |
| Mounting | Pole Mount |
| Lamp Life | 100,000 hours |
| Finish | Bronze |
| DLC | DLC Premium |
